Attribute Mapping

The most-used tab once you're past initial setup. It maps your custom WooCommerce attributes (taxonomies and product fields) to UnoPim attributes — scoped per channel and language.

Where it lives

WordPress admin → UnoPim Configuration → Field Mapping → Attributes.

Why per channel and language

Real catalogues often need this:

• On the web channel, color is a pa_color taxonomy.
• On the mobile channel, color is just a plain text field.
• On the b2b channel, color is irrelevant — sales reps don't need it on the listing.

Per (channel, language) scope lets you express all three on one screen without bleeding into each other. The language dimension matters less but is honoured for symmetry.

Page anatomy

┌─────────────────────────────────────────────────────────────┐
│  Channel: [web ▼]   Language: [en_US ▼]                     │
│                                                             │
│  ┌──────────────────────────────────┬──────────────────────┐│
│  │ WooCommerce field                │ UnoPim attribute     ││
│  ├──────────────────────────────────┼──────────────────────┤│
│  │ pa_color           [picker]      │ color   [picker]     ││
│  │ pa_size            [picker]      │ size    [picker]     ││
│  │ ...                              │ ...                  ││
│  ├──────────────────────────────────┴──────────────────────┤│
│  │ + Add WooCommerce field   + Add custom column           ││
│  │  Auto-map     Apply WC defaults    Save preset           ││
│  │  Save mapping     Clear     Refresh targets              ││
│  └──────────────────────────────────────────────────────────┘│
└─────────────────────────────────────────────────────────────┘

The table paginates 20 rows per page. Both columns are live, type-as-you-search pickers.

Scope picker

Two dropdowns at the top:

• Channel — defaults to your first channel
• Language — defaults to that channel's first language

Switching either:

1. Saves any pending changes (with a confirm if you have unsaved edits)
2. Loads the mapping for the new combination
3. Repaints the table

Each combination has its own row set. If you mapped color → color on web:en_US, switching to web:fr_FR shows a separate empty mapping (until you copy it via a preset).

Adding a row

Two paths:

Path 1: + Add WooCommerce field

Click + Add WooCommerce field. A new empty row appears. Click the left-side picker and start typing — matches come from:

• All your WooCommerce attribute taxonomies (the pa_* ones)
• All product fields with at least one stored value
• Standard fields like weight and dimensions
• Anything you've added via + Add custom column

Pick the WooCommerce field, then click the right-side picker and pick the matching UnoPim attribute. Done.

Path 2: + Add custom column

If you have a product field the auto-detection didn't pick up, click + Add custom column.

A small modal appears: type the field key (and an optional human label). The key now appears in the source-side picker.

Auto-map

Click Auto-map. The connector:

1. Loads the current channel's UnoPim attribute list.
2. For each WooCommerce source field that doesn't yet have a mapping, scores possible UnoPim attributes by code match, lower-case match, and label similarity.
3. Adds rows for the strongest matches.

A preview appears. Confirm to apply.

The button is non-destructive — your existing mappings are left alone. Click Clear first if you want a fresh slate.

Apply WC defaults

Inserts a baseline mapping for common WooCommerce field codes that have an obvious UnoPim equivalent (e.g. weight → weight, dimensions → dimensions, pa_color → color if those attributes exist on the active channel).

Useful as a starting point for a brand-new channel + language combination. Like Auto-map, it's non-destructive.

Presets

A preset is a named snapshot of your current scope's mapping.

Save preset

Click Save preset. A modal asks for a name (e.g. apparel_v2). Confirm.

Load preset

Click Load preset. Pick from the existing list. The current mapping is replaced with the preset's rows. Click Save mapping to commit.

When presets help

• Copy a mapping from web:en_US to web:fr_FR without re-doing every row.
• Roll back after a risky bulk edit (save before, load if it goes sideways).
• Replicate canonical mappings across channels.

Save, clear, refresh

Common patterns

Replicate a mapping across all languages of one channel

1. On web:en_US, click Save preset as web_default.
2. Switch to web:fr_FR. Click Load preset → web_default. Save.
3. Repeat for each language.

Replicate a mapping across all channels

Same as above, but switch the channel each time instead of the language.

Troubleshooting

The connector also exposes hooks for developers who need to extend it.

Next: Category Mapping
